Detail Produk
SPESIFIKASI
|
| Model | – | N04C-WY |
| Model Tipe | – | Mesin Diesel 4 Langkah Segaris; Variable Nozzle Turbocharger; Intercooler; Common Rail |
| Tenaga Maksimum | PS/rpm | 136 / 2.500 |
| Jumlah silinder | – | 4 |
| Diameter x Langkah Piston | mm | 104 x 118 |
| Daya maksimum | Kgm/rpm | 40/1.400-2.500 |
| Isi Silinder | cc | 4.009 |
| Tipe | – | Pelat Kering Tunggal; Hydraulic Operation |
| Diameter Cakram | mm | 300 |
|
| ||||||||
| Belakang | – | Full-floating; Single Reduction; Single speed by Hypoid Gearings |
| Depan | – | Reverse Elliot,I-Section Beam |
| Perbandingan Gigi Akhir | – | 6,833 |
|
| Ukuran Rim | – | 16 x 6.00GS-127 |
| Ukuran Ban | – | 7.50-16-14PR (LUG) |
| Jumlah Ban | – | 6 (+1) |
|
| Kapasitas | liter | 100 |
Jarak Sumbu Roda | mm | 3.380 |
Kabin Kesumbu Roda Belakang | mm | 2.900 |
Total Panjang | mm | 6.026 |
Total Lebar | mm | 1.945 |
Total Tinggi | mm | 2.154 |
Lebar Jejak Depan | mm | 1.455 |
Lebar Jejak Belakang | mm | 1.480 |
Julur Depan | mm | 1.066 |
Julur Belakang | mm | 1.580 |
| Depan & Belakang | – | rigid axle dengan pegas daun semi elliptic |
| Berat Kosong | Kg | 2.410 |
| GVWR / GCWR | Kg | 8.600 |
